Features

• Mulching Capable: Naturally recycles the grass by recutting it and feeding it back into your lawn.
• Smartchute®: Mow without the catcher and avoid sloppy grass clumps
• Chipperchute: With our additional chipper blade, shred branches up to 35mm in diameter turning them into useful mulch.
• Handle Lift System: Step on the foot pedal and lift the handle to quickly access the catcher, it is that easy!
• Adjustable Wheel Bearings: Ball bearing wheels make the mower easy to push and with a threaded axle and nut, the wheels are adjustable.
• Catcher ‘Full’ Indicator: Shows when the catcher is full – takes the guess work out of emptying the catcher.
• HDPE Plastic Catcher: High Density Polyethylene Plastic catchers.
• Ergo Adjustable Cam Locks: Multiple handle height adjustment to combat back strain. Easy fold down for storage.
• Masport Dual Mowzone®: Blade coverage extends beyond the wheel width on both sides allowing closer cuts to curbs, walls and fences, giving your lawn a tidier finish.
• Zone Start: The conveniently positioned starter cord eliminates the need to bend all the way down to pull-start, reducing the risk of back strain.
• Deck Washport: Hose fitting point on the housing to clean the housing while the mower engine is running, increasing the life of the deck and improving cutting efficiency.

Specifications

• Engine Make: Briggs & Stratton
• Engine Model: 700 Series™ DOV®
• Engine Type: 4 Stroke
• Engine Capacity: 161cc
• Power Rating (Torque): 7ft/lb or 9.52Nm
• Starting System: ReadyStart™
• Cutting Width: 485mm (19″)
• Cutting Height Range: 15mm – 75mm
• Cutting Methods: Cut, Catch, Mulch, Side Discharge, Chip
• Number of Blades: 5
• Cutting System: Masport 4 Blade Disc System with Chipper Blade
• Cutting Height Steps: 11
• Cutting Height Adjustment: Single Point
• Drive System: Push
• Chassis Material: Aluminium
• Upper Handlebar Type: MSV® with soft grip and Handle Lift System
• Handlebar Retainer: Ergo Adjustable Camlocks
• Lower Handlebar Type: Reinforced
• Catcher Type: HDPE Plastic
• Catcher Volume: 42L
• Wheel Bearing Type: Adjustable Dual Ball
• Wheel Type & Size: MSV® Mag Front 200mm (8″) and Rear 200mm (8″)
• Weight: 34.2kg
• Product Dimensions (W x H x L): 515mm x 1000mm x 1370mm

Resources

• Owners Manual (PDF): Download
• Warranty Card (PDF): Download
• IPL (PDF): Download
